8100
Aluminum Sliding Glass Door

Our 8100 series sliding glass doors are impact and non-impact panels that ride on one or more tracks. They roll smoothly by themselves or with additional panel layouts. We offer custom panel configurations, including pocketing panels and non-pocketing panels, as well as corner doors. WinDoor sliding glass doors offer one of the largest certified panels in the industry, at 12′ tall. Our Narrow and Wide Interlock options allow for stunning views while achieving the same excellent performance.

Available in 90- and 135-degree corners with multitrack configurations. Dual lock system and strong, durable 3”, Delrin rollers are standard. Feel protected behind our 8100 sliding glass door. Certified non-impact.

Brochure

Download PDF

Options & Accessories

Finish Options

Standard Single WinDoor Paint

10-Year Warranty
  • Hatteras White
  • Bermuda Bronze
  • Boca Tone
  • Costa Latte
  • Caribbean Crème
  • Custom Paint Available
5-Year Warranty
  • Clear Anodized
3-Year Warranty
  • White
  • Custom Paint Available

Single Woodgrain

10-Year Warranty
  • European Birch
  • Scandinavian Cherry
  • Himalayan Walnut
  • Honduran Mahogany
  • Applied woodgrain

2-Tone – Option of Different Interior & Exterior Finishes

10-Year Warranty
  • 2-Tone Standard WinDoor Paint Options
  • 2-Tone WinDoor & Custom Paint
  • 2-Tone Both Custom Paint
  • 2-Tone Applied Woodgrain & Paint
5-Year Warranty
  • Clear Anodized with Interior Custom Paint or Applied Woodgrain

Beauty
And Beyond

Gorgeous views are what we do at WinDoor, but we go beyond beauty to deliver windows and doors of unmatched quality and precision. Every day we challenge convention to offer industry-pushing designs built to perform, protect, and transcend the ordinary.

Handles

Note: All handle colors will match the frame color – unless otherwise noted. Contact your WinDoor Dealer for different color options.

The Signature Handle

Composite & Aluminum Handle
  • Optional Recessed Handle

The EuroHandle

Metal Handle

The Contemporary

14-Inch Off-Set Design

This handle is custom-made to order. Satin nickel oil rubbed bronze & polished chrome.

  • This handle is custom-made to order. Satin nickel oil rubbed bronze & polished chrome

Glass Options

Impact-Resistant & Non-Impact-Resistant Glass

  • Clear
  • Gray
  • Green
  • Azure Blue
  • Solar Cool Bronze
  • White Interlayer
  • Obscure
  • Available in Low-E
  • Insulated (Includes airspace for energy efficiency)
  • Single Glazed

Grilles (Muntin) Options

  • Insulated Glass – Applied muntins on both exposed surfaces of the glass and muntins within the airspace
  • Single Glazed – Applied muntins on both exposed surfaces of the glass
  • Standard & Custom Patterns Available
  • Flat Bar Muntins - 1” and 2" Profiles Available
  • Contoured Muntins - 1” and 2-3/4" Profiles Available

Technical Information

  • Sill Depth
    • 2-track = 5-1/8″
    • 3-track = 7-1/2″
    • 4-track = 9-7/8″
    • 5-track = 12-1/4″
  • Maximum Size
    • 4 feet wide x 12 feet high
    • 5 feet wide x 10 feet high
    • 5 feet wide x 12 feet high (9/16” Lami)
  • Glazing
    • Single Glazed
    • Insulated Non-Impact
    • Insulated LM & SM Impact
  • Performance
    • Non-Impact up to +100/-100 psf
    • Impact up to +125/-150 psf
  • Water
    • 1-3/4″ = 6.75 lbs
    • 2-1/4″ = 9 lbs
    • 3” = 12 lbs
    • 3-1/2″ = 15 lbs
    • 4-1/4” = 18 lbs
  • High Bottom Rail Option Available
